Customizing Microduck: How to Hack, Train, and Build on Pollen Robotics' Open-Source Biped

Small bipedal robots have long lived in an uncomfortable gap between fragile educational hobby toys and prohibitively expensive research rigs. For the past two years, the open-source community around Antoine Pirrone’s Open Duck Mini (the 3D-printable biped inspired by Disney’s BDX droid) pushed what was possible on a tight budget.

Now, through a collaboration with Pollen Robotics, that community project has evolved into Microduck: a ~25 cm tall, ~800 g bipedal robot with an industrial-grade, fully open-source software stack (Apache 2.0).

With fifteen Dynamixel XL330 smart bus servos, an onboard Time-of-Flight (ToF) sensor, real-time reinforcement learning locomotion, and a clean Rust-based daemon architecture, Microduck represents a modern reference platform for agile bipedal pets.

Here is an architectural deep dive into how Microduck works under the hood and how the open-source community can customize, train, and extend it.

---

1. The Hardware Architecture: Lean and Accessible

Microduck balances cost, weight, and low-latency motor communication:

• Compute: A Radxa Zero 3 SBC (Rockchip RK3566, quad-core Cortex-A55) running Armbian, with a 0.8 TOPS INT8 NPU sitting mostly idle for on-device perception work.
• Actuators: 15× Dynamixel XL330 smart bus servos on a single shared UART running Dynamixel Protocol 2.0 at 1 Mbps.
• Sensory Suite:
  • A head-mounted Time-of-Flight sensor (VL53L5CX/L8CX family) publishing an 8×8 depth matrix for obstacle awareness and, combined with leg odometry, 2D localization.
  • A dedicated motor-bus IMU board (LSM6DSV16X) with on-chip SFLP sensor fusion, so robotd reads an already-fused orientation quaternion straight off the same bus as the servos instead of integrating raw gyro/accel itself.
  • A front camera (IMX219) streaming over WebRTC for teleoperation and, increasingly, on-device vision.
• Procedural Sound Engine: No bulky audio libraries or canned MP3 files. Microduck uses microduck_sounds, a pure NumPy procedural synthesizer where sound profiles are dynamically generated from deterministic integer seeds. Changing a single seed completely alters the robot’s voice register, pitch, quackiness, and harmonic tilt.

---

2. The Software Stack: Rust Daemons Over Monolithic Middleware

Rather than saddling an ultra-lightweight SBC with heavy ROS nodes, Pollen Robotics designed Microduck around a cohesive, single-workspace Rust daemon architecture.

Each daemon owns a single responsibility and exposes a clean JSON-RPC interface over Unix domain sockets:

+-------------------------------------------------------------------+
|                           Microduck Host                          |
|                                                                   |
|  +--------+  +-------+  +---------+  +---------+  +------------+  |
|  |  padd  |  |  btd  |  | configd |  | mediad  |  |    tofd    |  |
|  |(Gamepad)| |(BLE)  |  |(Wifi/ID)|  |(WebRTC) |  |(ToF Depth) |  |
|  +---+----+  +---+---+  +----+----+  +----+----+  +-----+------+  |
|      |           |           |            |              |        |
|      +-----------+-----------+------------+--------------+        |
|                               |                                   |
|                               v                                   |
|                [ JSON-RPC 2.0 over Unix Sockets ]                 |
|                               |                                   |
|                               v                                   |
|                        +--------------+                           |
|                        |    robotd    | (50 Hz Control Loop)      |
|                        +------+-------+                           |
|                               |                                   |
|                               v                                   |
|                    [ Dynamixel Motor Bus ]                        |
|                               |                                   |
|                  (15x XL330 Actuators + IMU)                      |
+-------------------------------------------------------------------+

Seven daemons, each with exactly one unix socket and one job:

• robotd: The only process that touches the motors. Runs the 50 Hz control loop, reads IMU and joint telemetry, evaluates the ONNX policy, enforces fall-detection and thermal/joint safety limits, and is authoritative over anything that can hurt the robot. Clients only ever send intents; robotd decides what’s actually executable.
• tofd: Owns the head’s ToF sensor, publishing its 8×8 depth matrix. It reads nothing and answers no one — mediad and robotd just subscribe to its stream.
• mediad: The camera/audio pipeline and the WebRTC/remote gateway. Heaviest daemon on the board, deliberately split from robotd so a media crash can’t take out motor control.
• configd: Owns wifi, robot identity/naming, and gamepad Bluetooth pairing (bonding needs root and BlueZ, so it lives here rather than in the unprivileged padd).
• padd: A thin, unprivileged gamepad-input transport — reads the pad and forwards the same intents an app would send.
• btd: The BLE GATT transport a phone app uses to reach robotd/configd/updaterd when there’s no wifi.
• updaterd: A/B release management — verifies signatures, swaps releases atomically, health-gates against robotd, and rolls back automatically on a failed boot.

configd, updaterd, and btd deliberately have no dependency on robotd: they’re the recovery path for a robot whose control loop won’t start.

How to Customize the Software

Because all inter-process communication occurs via standard JSON-RPC over local Unix domain sockets, developers can write controllers, behavior state machines, or high-level agents in any language (Python, C++, Go, Rust) without touching the low-level motor drivers:

import socket
import json

# Connect directly to robotd's control socket
sock = socket.socket(socket.AF_UNIX, socket.SOCK_STREAM)
sock.connect("/run/robotd.sock")

# Send a standard JSON-RPC command (one object per line, NDJSON)
req = {
    "jsonrpc": "2.0",
    "method": "robot.move",
    "params": {"vx": 0.2, "vy": 0.0, "vyaw": 0.4},
    "id": 1
}
sock.sendall(json.dumps(req).encode() + b"\n")
response = json.loads(sock.recv(4096).decode())

---

3. Sim-to-Real: Training Custom RL Behaviors in MuJoCo

Microduck’s agility doesn’t come from classical inverse kinematics or hand-tuned spline trajectories; it runs deep reinforcement learning policies trained in simulation.

The training pipeline lives in microduck_rl, built on top of mjlab (MuJoCo Warp) using Proximal Policy Optimization (PPO):

1. Simulation Environment: The robot’s MJCF models are exported straight from Onshape CAD via onshape-to-robot, so the sim geometry and mass properties track the real hardware rather than a hand-tuned approximation.
2. Actuator Fidelity: At this scale, actuator dynamics dominate the sim-to-real gap more than rigid-body dynamics do. Rather than an ideal PD controller, microduck_rl models each XL330 with Rhoban’s BAM actuator model — voltage control law, back-EMF, and Coulomb/Stribeck/load-dependent friction — with domain randomization on battery voltage, voltage sag, command delay, and friction. A backlash variant of every task additionally simulates ±1° of gear play per joint.
3. Sim-to-Real Policy Export: Once a policy converges (thousands of parallel environments via MuJoCo Warp), scripts/export.py bakes the observation normalizer into the graph and exports to ONNX.
4. On-Device Inference: robotd loads the ONNX file directly into its 50 Hz execution loop. Because every task shares the same 61-dimensional observation contract, robotd can hot-swap between walk/recover/trick policies at runtime.

Training Your Own Custom Behaviors

microduck_rl already ships over a dozen registered tasks, and community members can fork any of them into new behaviors:

• Rolling Gait: A -Rollers variant of every task swaps in passive wheels under the feet, with dedicated RollerCrouch, RollerSlope, and RollerStandUp tasks for gliding and getting back up on wheels.
• Self-Righting: StandUp policies recover from face-down, face-up, or seated; VelStand folds walking and fall recovery into a single policy.
• Manipulation / Picking: GroundPick crouches and touches the ground with the beak tip; BallKick learns to kick a 70 mm ball forward.
• Acrobatics: Roulade trains a full forward roll over the head, landing back on the feet — a good example of how far a from-scratch reward function can push this platform.

To train a custom gait (requires a CUDA GPU and uv):

git clone https://github.com/pollen-robotics/microduck_rl.git
cd microduck_rl

# Train the main walking policy (~1-2h for a usable gait at 4096 envs)
uv run train Mjlab-Velocity-Flat-MicroDuck --env.scene.num-envs 4096

# Export the trained checkpoint to ONNX
uv run scripts/export.py Mjlab-Velocity-Flat-MicroDuck --wandb-run-path <entity/project/run_id>

Once exported, push the ONNX model to the robot and point robotd to your new policy configuration. No GPU on hand? --hf-jobs on any train command offloads the run to Hugging Face Jobs.

---

4. Community Roadmap: Where to Build Next

Microduck is designed as an open canvas, and more of the “roadmap” is already flying than you’d expect — the opportunity is extending it, not starting from zero:

1. SLAM & Local Navigation: microduck_maploc_rs isn’t a stub — it’s a working submap-based pose-graph SLAM stack with loop closure, boot-time Monte Carlo relocalization, and A* planning, driven purely by the head ToF sensor and leg odometry deltas. It’s already wired into the robot’s runtime behind a --maploc flag. The opening for contributors is porting it fully into the new robotd daemon architecture and building on top of it: frontier exploration, multi-floor maps, or smarter path smoothing.
2. Edge Vision & Object Tracking: The RK3566’s onboard NPU (0.8 TOPS INT8, via rknpu2) is largely untapped. A “recognize our own duck” detector — a small YOLOv8n/11n-class model reading raw NV12 frames from mediad — is already in progress for precise bearing tracking and follow-the-leader behavior, fusing camera bearing with ToF distance and BLE presence. Person-following, visual docking, and better dataset tooling (auto-labeling duck’s-eye-view footage) are wide open.
3. Multi-Robot Behaviors: Ducks already coordinate over BLE advertising, not the JSON-RPC control plane — robotctl chorale gets two or more ducks singing a synced four-part piece with no clock sync (~20 ms drift), and each robot advertises a stable id, RSSI-based proximity, and a shared beat other behaviors can read. That groundwork is the real opportunity: formation walking, beat-synced group motion, or turning chorale from a manual command into something ducks do spontaneously when they sense company.

---

Getting Started

All hardware designs, CAD files, firmware, and training code are completely open:

• Robot Brain & Daemons: pollen-robotics/microduck
• RL Training (mjlab / MuJoCo): pollen-robotics/microduck_rl
• Procedural Sound Engine: apirrone/microduck_sounds
• ToF-Based SLAM & Localization: apirrone/microduck_maploc_rs
• Blender Rigging & Reference Animation: pollen-robotics/Open_Duck_Blender

Microduck proves that bipedal robotics doesn’t require five-figure hardware budgets or closed commercial ecosystems. With open CAD, affordable smart servos, and accessible sim-to-real reinforcement learning, the foundation for accessible legged robotics is already here.
